The Conitel protocol was developed long before there were UARTs and microprocessors. It is not an asynchronous byte oriented protocol. Legacy protocols such as CDC type I/II, Conitel, TRW and Getac were of this bit- oriented design (and named after the companies that devised them) and. Converts bit Conitel SCADA protocol. (L&N Conitel) to Asynchronous Data. • External analog to digital conversion with the DCB T. • Internal 56/64 KBPS.
